Petroleum Product Semi Auto Digital Density Meter ASTM D1298 By Densitometer Method
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| MODEL | SH102F | Power | AC220V±10% 50Hz |
|---|---|---|---|
| Tube Capacity | 500ml | Temperature Measurement Range | 0-90℃ Or (customized -60℃-80℃); |
| Power Consumption | 2000W | Temperature Accuracy | ±0.1℃ |
| Standard | GB/T1884 ASTM D1298 DIN 51757 | Temperature Sensor | Industrial High Precision PT100 Sensor |
| Highlight | ASTM D1298 Digital Density Meter,Semi Automatic Digital Density Meter,Digital Density Meter By Densitometer Method |
||
Product Description
Petroleum Product SSemi- Automatic Digital Density Meter ASTM D1298 By Densitometer Method
SH102F microcomputer petroleum product density tester is designed and manufactured according to the requirements of the standard GB/T 1884 "Density determination of Petroleum and liquid petroleum Products (densitometry)" and SH/T2281 coking oil product density and ASTM D1298 DIN 51757. It is the liquid petroleum product density tester developed by our company. Suitable for measuring the density of crude oil and liquid petroleum products.
Petroleum Density Tester laboratory Testing Equipment ASTM D1298 Tester and ASTN D1298. Density Meter for Liquids ISO3675 and ASTM D1298,DIN 51757. JIS K2249,IP 160
Experimental Petroleum Products Density Analysis Meter
Petroleum Product Densimeter Densitometer Hydrometer ASTM D1298 Oil Density Meter
Hydrometer Method ASTM D1298 Petroleum Products Density Meter
Petroleum Product sSemi- Automatic Digital Density Meter ASTM D1298 byDensitometer method
Product Paramenters
| No. | Tech Indicator | Description |
| 1 | Power |
AC220V±10% 50Hz (Can be changed to your country request) |
| 2 | Tube capacity | 500ml |
| 3 | Temperature measurement range |
0-90℃ or (customized -60℃-80℃);
|
| 4 | Temperature Accuracy | ±0.1℃ |
| 5 | Power consumption | 2000W |
| 6 | Characteristics |
♦Constant Temperature Bath ♦LCD Display ♦Intelligent Control ♦Easy to Operation |
| 7 | Standard | GB/T1884 ASTM D1298 DIN 51757 |
| 8 | Temperature sensor | industrial high precision PT100 sensor |
| 9 | Instrument size:650*380*550mm weight: 42kg | |
| 10 | Packaging size: 720*450*580mm Packaging weight :48kg | |
| 11 | Data storage | USB disk data export function |
| 12 | Results output | can be equipped with USB output function, output to PC for long-term storage |
| 13 | Refrigeration mode | compressor refrigeration |
| 14 | Printer | equipped with micro printer |
| 15 | Printing interface | input density value, can automatically print oil density value. |
| 16 | Stirring device |
|
| Color LCD large screen display, full Chinese man-machine dialogue interface, no logo keyboard, | ||
Packing list
| S/N | Name | Quantity | Unit | Remarks |
| 1 | Host | 1 | set | |
| 2 | Water bath | 1 | piece | |
| 3 | Water bath cover assembly | 1 | set | 2 graduated cylinders can be placed |
| 4 | Power cord | 1 | piece | |
| 5 | Fuse tube | 1 | piece | |
| 6 | Measuring cylinder500ml | 2 | piece | |
| 7 | Instruction manual | 1 | copy | |
| 8 | Packing list | 1 | copy | |
| 9 | Warranty card | 1 | copy |
